What Is Development Length Of Bars

What Is Development Length ?

The development length can be defined as the length of the bar required for transferring the stress into the concrete.


In other words, development length is the quantity of the rebar length that is actually required to be enclosed into the concrete to make the desired bond strength between two materials and furthermore to produce required stress in the steel at that area.

Read – What is Lap Length Of Bar?

The development length Ld of a bar is calculated as following

Where d = diameter of the bar.

σs = stress in the bar at the section considered as design load.

τbd = Design bond stress.

In the below example, we need  10 db develop-ment length at the end section so that the concrete-steel bond stays continuous. The bar is bent because there is no space available at the end section. You can see that only 90-degree configuration is used but here we can use more configuration like that.

development length formula

The ascertained compression or tension reinforcement at every section of an RC member is produced on both sides of that section by hooks embedded length or mechanical gadgets.

Read – What Is Dowel Bar?

If the restraining section of concrete is relatively thin and unable to withheld the position of highly stressed bars the development length is given. In this way, the splitting of bars from concrete is avoided.

The additional embedded length is known as development length. The main aim is to give proper and settled support to the bars.

In compression reinforcement, hooks are not provided but where no or little space is available for extra length, hooks can be used for restraints.

Also Read – Estimating Steel For Reinforcement
Do you have any questions? Let me know in the comments.
